Manitowoc 2250 Service Maintenance Manual

Reference Only
Manitowoc Published 07-19-16, Control # 249-01 10-7
2250 SERVICE/MAINTENANCE MANUAL TROUBLESHOOTING
10
PROBLEM 5
Unable to build more than 6 bar (90 psi) air pressure.
POSSIBLE CAUSES
Safety valve, unloader valve, compressor, shut-off valve,
or bleed valve may be damaged.
CHECKS
Is gauge pressure more than 6 bar (90 psi)?
Yes No
Check that bleed valves are closed,
shut-off valve is open, and safety
valves are operating correctly.
Is unloader valve operating correctly?
Yes
No
Check compressor output.
Adjust or replace unloader valve.
Replace pressure sensor.
