Operating elements for driving
3.2 Short description of the operating elements
3 - 60 3 302 709 en Operating manual
GMK5150L
12.01.2018
3.2.14 Steering/separate steering
à Separate steering, p. 5 - 59
Instrument panel
Steering circuit 1 warning
Steering circuit 2 warning
Steering circuit 3 warning
(emergency steering pump)
Steering malfunction
–On: Engine off – ignition on
or
Engine on – fault, stop – check oil loss
–Out: Engine on – no fault
à p. 8 - 6
–On: approx. 10 km/h (6 mph) not reached
or
Steering malfunction – stop and check for oil loss
–Out: Emergency steering pump ready to function
à p. 8 - 6
1 After switching on the ignition
– Lit – goes out after about three seconds if there is no error
Whilst driving
– Lit (1 x warning buzzer) and goes out again
continued driving possible, error was saved
– Lit – symbol (2) yellow
3. and/or 4th axle still in straight running position,
continued driving possible, error was saved
à p. 8 - 7
