Manitowoc GROVE GMK5150L User Manual

Overview
1.5 Technical data
1 - 10 3 302 709 en Operating manual
GMK5150L
12.01.2018
1.5.3 Dimensions and weights of removable parts
This section contains the dimensions and weights of the parts that can be
removed for on-road driving;
à Driving modes, p. 6 - 1.
Spare wheel
Outrigger
Main boom
Description
Length x width x height
in m (ft)
Weight
in kg (lbs)
Spare wheel 385/95 R 25 1.36 x 1.36 x 0.40
(4.45 x 4.45 x 1.30)
245
(540)
Spare wheel 445/95 R 25 1.50 x 1.50 x 0.45
(4.95 x 4.95 x 1.50)
332
(732)
Spare wheel 525/80 R 25 1.50 x 1.50 x 0.53
(4.92 x 4.92 x 1.74)
362
(798)
Description
Diameter x Height
in m (ft)
Weight
in kg (lbs)
Plastic outrigger pad
diameter
0.50 x 0.16
(1.64 x 0.52)
25 (55)
Steel outrigger pad
diameter
0.50 x 0.16
(1.64 x 0.52)
50 (110)
Front outrigger
1)
,
complete per packet
2.80 x 0.30 x 1.10
(9.20 x 1.00 x 3.65)
950 (2,100)
Rear outrigger
1)
,
complete, per packet
2.80 x 0.35 x 1.10
(8.20 x 1.15 x 3.45)
1,050 (2,315)
1)
Consists of two sets
Description
Length x width x
height in m (ft)
Weight
in kg (lbs)
Complete main boom 13.50 x 2.00 x 2.10
(44.30 x 6.60 x 6.90)
15 000
(33 070)
Complete main boom 13.50 x 2.00 x 2.10
(44.30 x 6.60 x 6.90)
13 750
(30 315)
