Rigging work
12.9 Rigging/unrigging the counterweight
Operating manual 3 302 709 en 12 - 75
GMK5150L
12.01.2018
12.9.3 Identification
The truck crane and its corresponding counterweight sections are labelled
with the same serial number.
The base plate and the counterweight sections are labelled with the serial
number (1).
Depending on the version, other counter-
weight sections, e.g. blocks, are labelled
with a serial number (1).
S
Danger if counterweight sections are interchanged
Operate the truck crane only with the counterweight sections that belong to
it. The truck crane and counterweight sections are labelled with the same
serial number.
Other or additional counterweight sections may not be rigged.
