Malfunctions during crane operation
14.4 Troubleshooting
Operating manual 3 302 709 en 14 - 25
GMK5150L
12.01.2018
14.4.15 Malfunctions on the CCS/RCL control units
14.4.16 Malfunctions when driving from the crane cab
If this table does not help to remedy the malfunction;
à Malfunctions in the transmission, p. 8 - 23,
à Differential lock malfunctions, p. 8 - 22,
à Malfunctions of the steering, p. 8 - 24.
Malfunction Cause Solution
Control unit not working Power supply not switched on switching the ignition on
Fuse F1/4 blown Replace blown fuses;
à p. 14 - 75
Display is dark – LED flashes
blue
Ambient temperature too low Heat the crane cab
Display is dark – LED flashes
yellow
Ambient temperature too
high
Cool the crane cab
Display weak Ambient temperature too
high – brightness is reduced
automatically
The set brightness is restored
after cooling
Malfunction Cause Solution
The transmission, the dif-
ferential locks and the
separate steering do not
respond to the operating
elements – symbols grey
Parking brake applied Releasing the parking brake;
à p. 13 - 18
Ignition key in driver's cab
not in position 1
Turn the ignition key in the
driver's cab to position 1;
à p. 13 - 18
Button for separate steer-
ing has no function
Separate steering
switched off
à Switching on separate steer-
ing
, p. 13 - 13
Symbol for error appears
during differential locking
An illogical switching
state was recorded
If required, acknowledge
error message once and
briefly turn off the ignition –
it if occurs again, notify
Manitowoc Crane Care
