Malfunctions in driving mode
8.5 Emergency operation and breakdown assistance
8 - 28 3 302 709 en Operating manual
GMK5150L
12.01.2018
8.5.2 Battery charger
Prerequisites – The engine must not be running and must be secured against
unauthorised use.
– An external 230 V mains power supply must be available at the location.
– The location must be well ventilated and protected against moisture.
Connecting
• Insert the plug (2) into socket (1).
• Place the battery charger (4) in a protected
place where you can see the indicator
lamp (6).
The battery charger can be suspended from
the ring eyes (5).
• Insert the plug (3) into the socket on the
mains supply 230 V at the location.
The battery charger switches on. The lamp (6)
on the battery charger indicates the status:
Breaking
• Withdraw the plug (3) from the socket.
• Take out the plug (2) from the socket (1).
• Close the socket (1).
• Return the battery charger to the storage
compartment in the driver's cab.
G
Risk of explosion when operating the battery charger!
The battery charger may not be operated:
– At service stations and tank farms
– At places where flammable gases or vapours can be found or formed
(for example, at places where fuel is stored and in chemical factories)
– At places where explosive dust can be found or formed (e.g. carbon dust,
wood dust and grain dust).
– Flashing: The battery is being charged
–On: Charging complete
