Starting the engine for driving / switching it off
4.2 Switch off the engine
4 - 18 3 302 709 en Operating manual
GMK5150L
12.01.2018
4.2 Switch off the engine
4.2.1 At the ignition lock and with the outrigger control units
If the temperature of the coolant is very high, let the engine run on for
another one or two minutes at increased idling speed.
Ignition lock
• Turn the ignition key to position 0 – the engine will stop.
Outrigger control units:
• Press the button (1) – the engine will switch off.
After switching off If you want to park the truck crane;
à p. 5 - 46.
G
Risk of accidents because the truck crane cannot be steered.
Switch the engine off only once the truck crane has come to a standstill. If
you remove the ignition key, the steering will lock and you will lose control
of the moving truck crane.
