Driving with a rigged truck crane
13.2 Permissible rigging modes and axle loads
Operating manual 3 302 709 en 13 - 5
GMK5150L
12.01.2018
13.2.1 To drive without a load
•
Bring the main boom to an inclination permitted within the working range.
• Tie down the hook block so that it cannot swing around.
13.2.2 To drive with a load
When the truck crane is being driven with a lifted load, it may be driven only
from the crane cab.
• Lift the load.
• Bring the main boom to an inclination permitted within the working range.
• Lock the turntable in the 0° to the rear position; à p. 13 - 7.
• Enter and confirm the rigging mode according to Lifting capacity table for
the current
Free on wheels, 0° to the rear working position.
• Tie down the load so that it cannot swing back and forth.
• Before driving with a load, observe the specifications in the relevant
section;
à Driving from the crane cab, p. 13 - 17
G
Risk of accidents when driving with a lifted load
When driving with a lifted load, you must be able to operate the crane at
any time in the event of an emergency. That is why the truck crane may not
be driven from the driver's cab with a lifted load.
G
Risk of accidents when driving with a lifted load
Secure the load when driving so that it cannot swing and use the transmis-
sion mode DM or RM so that the transmission does not shift.
In this way you can prevent the swinging load leaving the permissible
working range and the truck crane overturning.
