Manitowoc GROVE GMK5150L

Operating elements for driving
3.2 Short description of the operating elements
Operating manual 3 302 709 en 3 - 55
GMK5150L
12.01.2018
3.2.11 Transfer case
à Transfer case – switching the off-road gear on/off, p. 5 - 50
Driving menu
Transfer case for off-road gear on/off
Transfer case display
The current status is shown using different
symbols:
Transfer case for off-road gear on/off
Switching towing mode on/off;
à p. 8 - 31.
Opening: Select symbol (1) and confirm – menu is opened
– Switch on: Select symbol (2) and confirm – off-road gear engaged
– Switch off: Select symbol (1) and confirm – off-road gear disengaged
1 Off-road gear on
2 Off-road gear off – on-road driving
3 Select neutral
4 Error – violet
