Operating elements for driving
3.2 Short description of the operating elements
Operating manual 3 302 709 en 3 - 65
GMK5150L
12.01.2018
3.2.16 Lighting/windscreen wipers/horn
Steering column Multipurpose switch
Headlight flasher/headlight – full beam
Turn signal indicator/wiper-washing system
Steering wheel
Horn
The ignition is switched on
Instrument panel
Checking headlight – full beam
s
1 Parking light/headlight: Middle position
2 Flash the headlights: Upwards
The parking light/headlight must be switched on:
3 Headlight – full-beam: Down – latches into place
4 Right turn signal indicator: Forwards
5 Left turn signal indicator: Backwards
6 Windscreen wiper/washing system: Press
7 Windscreen wiper: Rotate:
–Off
– Interval – slow
– Interval – fast
– Continuous wiping – slow
– Continuous wiping – fast
–Press: Carrier horn on
1–On: Headlight – full beam on
–Out: Headlight – full beam off
2 – Lights up Headlight flash
