Starting/switching off the engine – for crane operation
10.2 Starting the engine – from the crane cab
Operating manual 3 302 709 en 10 - 5
GMK5150L
12.01.2018
10.2.3 Switching the ignition on
H
Do not start the engine until the CCS display shows a menu (usually the
Enter rigging mode menu).
• Turn the ignition key to position 1.
The ignition is switched on:
– The vehicle parking brake must be engaged. The lamp (1) lights up –
symbol (2) – red.
– The transmission must be switched to neutral position – symbol (1).
If the symbol (1) is grey then switch the ignition off and on again.
After switching on the ignition, a lamp test is performed and switching
states are checked.
