Driving with a rigged truck crane
13.5 Driving from the crane cab
13 - 32 3 302 709 en Operating manual
GMK5150L
12.01.2018
13.5.7 After driving
•
Bring the truck crane to a halt with the brake pedal (1).
• Restore the original condition:
– Switch the transmission to neutral
position (1)
– Switch off longitudinal differential lock (3)
– Switch off transverse differential locks (2)
– Switch on normal steering mode (4)
• Press button (7) down once. The lamp (6)
lights up, symbol (5) is red – the parking
brake is applied.
• If necessary, switch the engine off; à Switch off the engine, p. 10 - 11.
• Remove the ignition key from the ignition lock in the driver's cab and lock
the driver's cab to prevent unauthorised access.
Put the truck crane on outriggers if you do not intend to work in the
Free-on-wheels working position.
