Rigging work
12.5 Starting the engine for rigging
Operating manual 3 302 709 en 12 - 29
GMK5150L
12.01.2018
12.5.2 Starting/shutoff the engine – from the outrigger control units
Prerequisites The following requirements must be met before you can start the engine for
driving from the outrigger control units:
– The ignition in the driver's cab must be switched on.
– The ignition in the crane cab must be switched off.
– The lamp (1) lights up.
Starting
the engine
All activities and inspections required to start the engine must be carried out
before starting the engine;
à p. 4 - 1.
• Press the button (1) once – the engine will start.
Switch off
the engine
• Press the button (1) once – the engine will switch off.
