Rigging work
12.5 Starting the engine for rigging
12 - 28 3 302 709 en Operating manual
GMK5150L
12.01.2018
Starting
the engine
All activities and inspections required to start the engine must be carried out
before starting the engine;
à p. 4 - 1.
• Wait until the lamps (1) and (2) light up.
If the lamp
(2) does not illuminate or flash after approx. 20 seconds, there is
a malfunction;
à p. 14 - 23.
• Press the (3) button once – the engine starts.
The following buttons are now active on the hand-held control:
– All buttons on the control panel (1).
– The function buttons (3).
– All buttons on the control panel (4).
– The button (6) for the horn on the carrier.
The
button (2) and button (5) are inactive.
The
Outriggers control units are locked after connection of the hand-held
control.
Turning off
the engine
If the engine was started with the hand-held control, you cannot switch off
it off at the ignition lock in the driver's cab,
• Press the button (1) once – the engine will switch off.
