Starting/switching off the engine – for crane operation
10.2 Starting the engine – from the crane cab
10 - 4 3 302 709 en Operating manual
GMK5150L
12.01.2018
10.2.2 Checks before starting the engine
Checks on the
carrier
All checks and switch positions for the first engine start of the day must be
performed;
à p. 10 - 1.
Checking the
hand-held control
Hand-held control removed
• Check that the bridging plugs are inserted into all sockets for the hand-
held control;
à p. 9 - 150.
Hand-held control connected to the superstructure
After starting the engine, you can use the hand-held control to execute all
functions which are provided from this socket.
At the hydraulic
tank
Before you start the engine, all valves on the hydraulic tank must be open.
The flap is located behind the valve (1).
• Check that the valve is open – lever (1)
parallel to the pipe.
If the valve is closed
• Pull the knob (2) and open the valve.
S
Risk of damage to hydraulic pumps
You may only start the engine when all the valves on the hydraulic tank are
open!
