Manitowoc GROVE GMK5150L User Manual

Malfunctions during crane operation
14.4 Troubleshooting
Operating manual 3 302 709 en 14 - 23
GMK5150L
12.01.2018
14.4.10 Malfunctions when operating with the hand-held control
14.4.11 Malfunctions when inclining the crane cab
14.4.12 Malfunctions when raising the axles
Malfunction Cause Solution
After connection:
The
CAN lamp does not
light up or blinks
Some other socket is
lacking a bridging plug
Insert bridging plug;
à p. 12 - 25
Crane cab: Fuse F3/6 blown Replace the blown fuse;
à p. 14 - 75
Pre-selected function can-
not be performed
Another function has been
pre-selected
Pre-select the desired
function
Operation not possible Malfunction in the control
system
Inform
Manitowoc Crane Care
Malfunction Cause Solution
Crane cab inclination function
not working
Control unit fuse blown Replace the blown fuse;
à p. 14 - 75
Malfunction Cause Solution
The menu cannot be opened Suspension is switched on Switching off the suspension;
à p. 5 - 16
Operating elements not
working
Outrigger menu open Open the Raise axle menu;
à p. 12 - 66
Operating elements not
working
Maximum permissible
pressure exceeded
Re-align the truck crane to
relieve the load;
à p. 12 - 60
