Operating elements for driving
3.2 Short description of the operating elements
3 - 74 3 302 709 en Operating manual
GMK5150L
12.01.2018
3.2.23 Windows and doors
Window winder
Button assignment
Movement stops after the button is released
and when an end position is reached.
Jog function
Press button (1) briefly – the window opens all
the way to the end position.
Press button (2) briefly – the window closes all
the way to the end position.
G
Risk of crushing when closing the windows
If the window winders encounter resistance, they do not stop but keep on
moving at reduced power.
A Window winder, driver's door
B Window winder, passenger door
1 To open the window
2 To close the window
