Driving
5.3 Driving the truck crane and switching it off
Operating manual 3 302 709 en 5 - 37
GMK5150L
12.01.2018
Monitoring
elements
• Also pay attention to the monitoring elements.
Tachometer
Fuel level display
Never run the fuel tank completely dry; always refuel in time;
à p. 4 - 5.
If the fuel tank is almost empty, air can be sucked in and the fuel system
must then be bled;
à Maintenance manual.
Adblue filling level indicator
If possible, never run the
Adblue tank completely dry; refuel in due time;
à p. 4 - 7.
If the
Adblue tank is empty, the lamp (1) lights and the slewing moment is
reduced;
à p. 5 - 45.
Coolant temperature display
1 Green: Economic consumption
2 Yellow: Engine brake active
3Red: Engine speed too high – danger;
à Checks when driving downhill, p. 5 - 42
1 Coolant temperature display in degrees Celsius
In the event of malfunctions;
à p. 8 - 19
