Driving modes and rigging for on-road driving
6.1 Driving modes
6 - 4 3 302 709 en Operating manual
GMK5150L
12.01.2018
Tyres
445/95 R25
Also observe the effects on the axle loads when towing a trailer;
à p. 5 - 81.
Driving
mode
123
Equipment
Drive 10 x 6 x 10
✔
Drive 10 x 8 x 10
✔✔
Retarder
✔✔✔
Rear bumper
✔✔✔
Auxiliary hoist or 1.0 t counterweight installed
✔✔✔
Rigging mode
445/95 R25 spare wheel on rear
Storage box at the rear of the carrier, loaded
with 150 kg
●
Hydraulic hose drum on the main boom ●●●
1.8 m + 16 m swing-away lattice is folded to
the side,
●●●
2.0 m heavy load lattice extension, folded to
the side
4.6 t counterweight attached to the turntable ●●●
2.3 t counterweight on the counterweight platform ●●●
1 -sheave hook block attached to the bumper
1)
3 -sheave hook block attached to the bumper
1)
Hook tackle hung on the bumper
1)
●●●
1)
The weight of the hook blocks is based on the information in these
operating instructions;
à p. 1 - 11.
