Malfunctions in driving mode
8.6 Tilting/lowering the driver's cab
8 - 44 3 302 709 en Operating manual
GMK5150L
12.01.2018
8.6.2 Tilting and lowering the driver's cab
Operating the
hand pump
The driver's cab is tilted and lowered using a hand pump. The lever for the
hand pump is below the seats or in the tool box.
• Insert the lever (1) into the hand pump (3).
• To tilt the driver's cab, turn the lever (2)
forward to position A.
• To lower the driver's cab, turn the lever (2)
backwards, to the B position.
Before tilting the driver's cab, note the prerequisites specified at the begin-
ning of the section;
à Prerequisites and information on tilting, p. 8 - 43.
