Malfunctions in driving mode
8.7 Fuses on the carrier
Operating manual 3 302 709 en 8 - 53
GMK5150L
12.01.2018
s
Designation Amperage (A) Function
F6/1 5
Engine emergency stop switch
Tachograph, instrument panel
F6/2 3
Control unit CCM 11
Control unit IOL 31/32/33
F6/3 3
Display
CCS
Reverse camera
Radio
F6/4 5 Air intake inhibitor
F6/5 10 Gearbox control
F6/6 5 Engine/transmission diagnostics plug
F6/7 3
Outrigger control unit left/right
Inclination transmitter
F6/8 3
Engine electronic control system
AdBlue system
Designation Amperage (A) Function
F7/1 3 Alternator
F7/2 3 Brake circuits 1 and 2
F7/3 3 Auxiliary heater time switch
F7/4 15 Retarder
F7/5 5
Horn
Soot particle filter
F7/6 - Unassigned
F7/7 10
Operating the mirror adjustment
Window winder
F7/8 - Unassigned
