Operating elements for crane operation
9.2 Short description of the operating elements
Operating manual 9 - 117
GMK5150L
CCS display
Power units display
High speed monitoring for the hoists
Lift/lower the hoist display
Warning for lowering limit switch shutdown
Warning for lifting limit switch shutdown
Overriding the lifting limit switch
– Green: Auxiliary hoist on
–Red: Auxiliary hoist off
–On: High-speed mode on
–Out: High-speed mode off
à p. 11 - 113
– Symbol (1): Lifting
– Symbol (2): Lowering
à p. 11 - 113
–Red: Lowering limit switch triggered – auxiliary hoist stop
–Grey: Lowering limit switch not triggered
à p. 11 - 82
1 Short description with main hoist;
à p. 9 - 116
2 Short description with main hoist;
à p. 9 - 115
