Operating elements for crane operation
9.3 Short description of the operating elements – driving from the crane cab
9 - 164 Operating manual
GMK5150L
CCS display
Changing the steering direction
Display
ltr
– Steering direction Steering wheel
– Steering direction Reversed
à Switching the steering direction, p. 13 - 23
1 Steering direction
Steering wheel
2 Steering direction Reversed (compared to steering wheel)
To switch over: Select desired symbol and confirm
The setting will be secured
Function
– Press button (1) to the right = wheels turn to the right –
steering wheel turns to the right
– Press button (1) to the left = wheels turn to the left –
steering wheel turns to the left
Function
– Press button (1) to the right = turn wheels to the left –
steering wheel turns to the left
– Press button (1) to the left = wheels turn to the right –
steering wheel turns to the right
