Crane operation
11.5 Crane operation with main boom
Operating manual 3 302 709 en 11 - 81
GMK5150L
12.01.2018
You can set the desired engine speed (idling speed) with button (1);
à p. 10 - 9.
Maximum
permissible hoist
rope speed
The maximum permissible hoist rope speed is limited automatically
depending on the degree of utilisation of the lifting capacity and reeving.
The scale of the limitation is specified in the supplied
Lifting capacity table.
The current speed reduction is displayed in the start menu;
à p. 9 - 19.
You can limit the maximum telescoping speed in the
Power unit speed menu;
à p. 11 - 125.
Switching off the
auxiliary hoist
If the auxiliary hoist is not required, it should be switched off to avoid
unintentional use.
• Press the button (1) once.
– The lamp in the button (1) will light up dimly.
– Symbol (2) is red when the auxiliary hoist is switched off.
