Crane operation
11.5 Crane operation with main boom
11 - 100 3 302 709 en Operating manual
GMK5150L
12.01.2018
You can switch on high-speed mode for a higher speed; Ã p. 11 - 113.
You can set the desired engine speed (idling speed) with button (1);
à p. 4 - 17.
You can limit the maximum telescoping speed in the
Power unit speeds menu;
à p. 11 - 125.
Switching off
the telescoping
mechanism
If the telescoping mechanism is not required, it should be switched off to
avoid unintentional use.
• Press the button (1) once.
– The lamp in the button (1) will light up dimly.
– The symbol (2) red if the telescoping mechanism is switched off.
If the control lever is assigned more than one function, the derricking gear
will also be switched off if you switch on another power unit which is
assigned to the same control lever movement;
à Control lever assignment,
p. 9 - 14.
