Driving with a rigged truck crane
13.2 Permissible rigging modes and axle loads
Operating manual 3 302 709 en 13 - 3
GMK5150L
12.01.2018
10.2
(22,487)
50 - 0 - 0 - 0 - 0 20 - 40 front 15.5 (34.2) 12.5 (27.6)
0 - 0 - 0 - 0 - 0 80 rear 12.5 (27.6) 12.5 (27.6)
12.5
(27,558)
50 - 0 - 0 - 0 - 0 20 front 15.0 (33.1) 12.0 (26.5)
0 - 0 - 0 - 0 - 0 65 - 80 rear 13.5 (29.8) 14.5 (31.9)
14.8
(32,628)
50 - 0 - 0 - 0 - 0 20 front 14.0 (30.9) 13.0 (28.7)
0 - 0 - 0 - 0 - 0 60 - 80 rear 14.5 (31.9) 15.5 (34.2)
17.1
(37,699)
50 - 0 - 0 - 0 - 0 20 front 13.5 (29.8) 14.5 (31.9)
0 - 0 - 0 - 0 - 0 70 - 80 rear 15.0 (33.1) 14.5 (31.9)
19.4
(42,770)
50 - 0 - 0 - 0 - 0 20 front 12.5 (27.6) 15.5 (34.2)
0 - 0 - 0 - 0 - 0 80 rear 16.0 (35.3) 13.0 (28.7)
21.7
(47,840)
50 - 50 - 0 - 0 - 0 20 front 16.0 (34.2) 14.0 (30.9)
0 - 0 - 0 - 0 - 0 70 rear 15.0 (33.1) 15.5 (34.2)
24.0
(52,911)
50 - 50 - 0 - 0 - 0 20 front 15.0 (33.1) 15.5 (34.2)
0 - 0 - 0 - 0 - 0 70 rear 15.0 (33.1) 16.0 (35.3)
26.3
(57,982)
50 - 50 - 0 - 0 - 0 20 front 14.5 (31.9) 16.5 (36.4)
0 - 0 - 0 - 0 - 0 65 rear 15.5 (34.2) 15.5 (34.2)
30.9
(68,123)
50 - 50 - 50 - 0 - 0 20 front 15.5 (34.2) 17.5 (38.6)
0 - 0 - 0 - 0 - 0 65 rear 17.5 (38.6) 16.0 (35.3)
44.5
(98,106)
50 - 50 - 50 - 50 - 50 20 front 14.0 (30.9) 23.0 (50.7)
0 - 0 - 0 - 0 - 0 50 rear 20.0 (44.1) 19.0 (41.9)
Counter
weight
in t
(lbs)
Telescope status
I - II - III - IV - V
in %
Main boom
Angle
in °
Superstruc-
ture position
1)
Axle load
2)
in t (x 1,000 lbs)
front rear
1)
Rear: Display, slewing angle 0°
Front: Display, slewing angle 180°
2)
Front: on the first and second axle lines respectively
Rear on the 3rd, 4th and 5th axle line
