Driving with a rigged truck crane
13.5 Driving from the crane cab
Operating manual 3 302 709 en 13 - 27
GMK5150L
12.01.2018
Normal steering
mode
When driving a rigged truck crane, always use the separate steering;
à p. 13 - 24.
Switching to normal steering mode
• Use buttons (1) and (2) to turn the wheels to
the
Straight ahead position – the current
wheel position is displayed.
• Select and confirm the symbol (3) – display
symbol (4).
If the error symbol is displayed, contact
Manitowoc Crane Care; Ã p. 8 - 24.
Steering in normal steering mode
The (2) symbol is displayed.
• Steer the 1st and 2nd axle lines with the button (1).
The wheels of the 3rd to 5th axle lines are turned correspondingly for
driving around the corner.
– To turn to the left: • Press button (1) to the left.
– To turn to the right:
• Press button (1) to the right.
