Manitowoc GROVE GMK5150L User Manual

Malfunctions during crane operation
14.3 Warning and error messages
Operating manual 3 302 709 en 14 - 11
GMK5150L
12.01.2018
– Lattice extension angle too small
Raise the lattice extension;
à Lattice extension operating manual.
– Lattice extension angle too large
Lower the lattice extension;
à Lattice extension operating manual.
– Boom extension angle not measured (different sensor values)
– Main boom, lifting capacity table not present
– Lattice extension, lifting capacity table not present
– RCL override (switch 1) not actuated
– RCL override (switch 1) actuated
– RCL override (switch 2) not actuated
– RCL override (switch 2) actuated
