Symbols & References
The table below lists symbols used throughout this document. Bold square brackets [ ] have been
used in this manual to denote a button or key function on the operator control console.
symbol
[ ] ref
meaning
General caution
Indicates general cautionary, warning, or danger level
information
Electrical shock caution
Indicates possibility of electric shock under specific conditions
[JOG]
JOG mode selection
[MDA]
MDA mode selection
[AUTO]
AUTO mode selection
[TEACHIN]
TEACHIN mode selection
[SBLK]
SINGLE BLOCK mode selection
[RESET]
RESET program cycle, alarm message
[CYCLE
START]
CYCLE start request
