Operating Manual
T 700 / T 800 - FP ENG
2.3 Safety devices - machine
2.3.1 Protective hoods - Checklist of parallel unit/feeder and mobile folding units
Pos Identification Function control Visible control Result Note
1 Two-pieced protective
hood over
p
arallel unit
2 Protective hood over
slitter shafts
Locked electron. if hood is
open ”V“ = 70 mtrs/Mte.
(tipping mode)
3 Guard over foldrollers
4 Guard over parallel
unit
at drive and operator side
5 Cover handwheel at drive and operator side
6 Guard over drive of
suction tape or
suction wheel
at drive side
8 Guard over drive of
suction tape or
suction wheel
9 Protective angle
before suction tape or
suction wheel
See page of Operating
Manual for Setting
Instructions
10 Guards over
handwheel
11 Guard plate below
parallel unit
at exit of folding unit
12 Guards above drive
belt cross carrier
At drive side
13 Guards before drive
belt Cross carrier
At drive side
22 Guard over drive shaft
of suction wheel
at suction wheel and
suction tape
23 Guard over pulley for
suction wheel
at suction wheel and
suction tape
24 Guard over chain lead
25 Guard over
adjustment pulley
at drive side
26 Guard over drive
chain
at drive side
27 Guard over drive shaft
for feeder
at drive side
28 Guard over Vaculift
29 Guard over motor for
Vaculift
30 Guard over chain lead
31 Pile plate automatical stoppage
when plate is 120 mm
above floor; remainder
through tipping mode
Date Name Signature
