Seite 71Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
5.7.4 Control panel - Push button control (Optional)
1 Red mushroom button with locking for EMERGENCY STOP
2 Button to STOP the machine
3 Button to START the machine
4 Sheet infeed button for PRODUCTION
5 Button for SINGLE SHEET INFEED
7 Selector switch for set-up mode (see para. 5.7.6).
Position I: Set-up mode.
Position 0: Position of switch during production
8 Push button to increase speed of folding unit
9 Push button to reduce the speed of folding unit
10 Push button for joint speed alteration of all folding units
(push simultaneously with buttons 8 or 9).
> NOTICE < If the guard above the slitter shaft is opened the machine will stop immediately.
ERROR 22 will appear on the MC counter.
