Page 36
Alterations reserved Stand 12/2002
Operating Manual T 700 / T 800.1 - R ENG
4.2 Lubrication / Cleaning
>NOTICE< Generally, the machine should be cleaned after each job, particularly moveable
parts which have been changed due to change of sheet size, because heavy dust may cause
reduction of function.
4.2.1 Feeder
Remove cover 1 at drive side
and slighty lubricate the
chain 2 with oil occasionally.
Replace cover 1.
4.2.2 Register table
Clean the guide shaft for sheet size
adjustment 1 as well as drive shaft 2
off from dust and provide them
with a slight touch of oil.
