3.1.2 Feeder
Unscrew the feeder off the pallet
and move it with a fork lift.
Set the fork lift onto the transport bars 1
to the final position.
3.1.3 Folding units II and III
Unscrew the units II and III
off the pallet and lift them
with a forklift at cross bar 1.
> ATTENTION < The unit may fall (tip)
over wherefore two additional persons
are required to brace the unit.
Make sure that machine rollers 2
and castor wheel 3 will not be
damaged when dropping the unit.
3.1.4 Cleaning
> ATTENTION < Clean the machine, feeder, and delivery of rust preventing agents.
