Page 35Alterations reserved Stand 12/2002
Operating Manual
T 700 / T 800.1 - FP ENG
4.1.8 Toothed belt for rear twin-perforator shafts (option)
Tensioning of toothed belt 1:
Loosen nut 2 and turn excentric 3.
Refasten 2 again.
