Page 46
Alterations reserved Stand 12/2002
Operating Manual T 700 / T 800 - R ENG
5.2.3 Lower table
Use the guide plate 1 and pin 2
for exact positioning of the paper.
>NOTICE< Jam will occur
if sheets are pinched!
For safe sheet separation set
the rollers 3 and brush 4
to the end of approx. 2-5 top sheets.
Set the pressure through weights 5.
Positioning: Loosen the grip 6
and turn knurled grip 7.
Set the required length measurement
at mm-scale 8 of the sheet
to be processed.
