5.5.15 Twin-rear slitter shafts (Option) - Applications
Extremely flexible, many cutting, scoring and perforating knives can be used while increasing the
accuracy of processing at the same time.
>NOTICE< Place the cutting, scoring and perforating knives on the first set of rear slitter shafts 8.
The second set 9 serves as additional sheet guidance.
>NOTICE< If you place the cutting, scoring and perforating knives in very small distances to
eachother: Use both sets of slitter shafts 8 and 9 to ensure that you have enough space for the
rubber transporting rollers between the knives
>NOTICE< For installation of various tools onto the set of slitter shaft 8, it is adviseable to remove
the set of slitter shafts 9.
