Seite 22
Alterations reserved
Stand 05/2008
Operating manual T700/T800.1 - en
3.2.3 Pressure-/vacuum pump
The pump has been installed under
the feeder table by the manufacturer,
as well as all pressure and
vacuum tubes.
Affix noise reducer 1.
> ATTENTION < Check the rotating
field. If this is not correct it may
cause essential damage to
the pressure-/vacuum pump.
3.2.4 Double sheet control
Attach the double sheet control 1
with screw 2 and
the cable with screw 3.
