Page 22
Alterations reserved Stand 12/2002
Operating Manual T 700 / T 800 - R ENG
3.2.3 Pressure-/vacuum pump
The pump has been installed under
the feeder table by the manufacturer,
as well as all pressure and
vacuum tubes.
Affix noise reducer 1.
>ATTENTION< Check the rotating
field. If this is not correct it may
cause essential damage to
the pressure-/vacuum pump.
3.2.4 Double sheet control
Attach the double sheet control 1
with screw 2 and
the cable with screw 3.
