Seite 43Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
5.3 Feeder
5.3.1 Upper pile table
Set the lateral sheet stop 1 with
knurled grips 2 to ½ of sheet width;
use mm-scale 3.
For pile transportation ON/OFF:
Use blue button 4 at feeder table
or blue push button at
main control panel 7.
Place a bulk of sheets onto
the feeder table and
shingle 6 them with a spatula 5.
Bear in mind that maximum
loading height is approx. 8 cm.
Use extension bars 7 when you
process long sheet sizes.
Use rollers 8 for short oblong sheets.
