Seite 87Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
7.0 Options
7.1 Batch counter
The counting functions of the standard batch counter MCC 3 are integrated into the ”MC
Control” and are described as ”MC Control” in the attached Operating Manual. Should,
however, another counter have been installed by the manufacturer, its Operating Manual is
also attached separately.
7.2 Gully cut
Place the knife holder 1 onto the
upper slitter shaft. Insert two knives 2
with their cutting edge to the outside
and place two counter knives 3
against them on the lower slitter shaft.
Width of cut:
Minimum = 4 mm, maximum = 15 mm
The thicker the product the wider
the cut! Combine distance washers 4
of 0.3 - 5 mm.
Always
insert a stripper 5 between
the counter knives 3.
Use a stripper 6 between
the cutting knives only when
you process bulky products.
