3.2.5 Noise damping hoods (optional)
Noise hoods 1 and 2 are
installed by the manufacturer.
3.2.6 Guard above the slitter shafts
> DANGER < Check
of the safety switch 1:
If the guard 2 is lifted the
safety switch 1 must activate.
If setting becomes necessary,
loosen the screw 3 through
hexagon key SW 1.5 mm and turn
the axe 4 into the required position.
