Page 42
Alterations reserved Stand 12/2002
Operating Manual T 700 / T 800.1 - FP ENG
4.2.8 Pressure/Vacuum Pump
The cleaning of the pump depends on the use of the folding machine.
It may become necessary weekly or at infrequent intervals. Please check separate
Operating Manual of manufacturer.
>NOTICE< To ensure full efficiency, however, the cartridge at suction side should be checked
and cleaned occasionally. The filtre cartridge must be cleaned every 50 hours of operation
and be exchanged every 6 months. Dirty or damaged cartridges must be replaced immediately.
Do not remove the filtre cartridge in any case, otherwise penetration of foreign substances
will damage the pump. Make sure that pump is turned OFF during maintenance works.
Remove cap 1 and 2,
as well as filtre cartridges 3, 4 and 5.
Clean these cartridges
by blowing through from
the internal to the external side.
Exchange cartridges every six months.
