25 - 1
25
25
BAR CODE READER
CONNECTION
26
CNC CONNECTION
27
MULTI-CHANNEL
FUNCTION
28
FA TRANSPARENT
FUNCTION
29
MULTIPLE-GT11
CONNECTION FUNCTION
30
GATEWAY FUNCTION INDEX
BAR CODE
READER
CONNECTION
25.1 System Configuration . . . . . . . . . page 25-2
This section describes devices and cables needed for bar
code reader connection.
Refer to this section to select the desired system.
25.2 Preparatory Procedures for Monitoring . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . page 25-4
This section describes the preparatory procedures for the
monitoring in the bar code reader connection.
The sequential checkup procedure will be helpful for those
who communicate through the GOT for the first time.
25.3 Precautions . . . . . . . . . . . . . . . . page 25-14
This section describes the precautions for bar code reader
connection.
Refer to this section without fail before starting bar code
reader connection.
25.4 System Configuration Examples . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . page 25-15
This section describes system configuration examples of
the bar code reader connection.
25.5 List of Functions Added by Version Upgrade
. . . . . . . . . . . . . . . . . . . . . . . . . page 25-19
This section describes the functions added by version
upgrade of GT Designer2 or OS.
