4 "Bar Code" in GT Designer2
*1 Keep consistency with the bar code reader setting.
"Bar Code" in GT Designer2
For the "Bar Code" setting in GT Designer2, refer to the following manual.
GT Designer2 Version Screen Design Manual
Item Setting
Device D0
Device Points 6
Header
*1
None
Terminator
*1
CR
Writing Byte Order
Low High
Fills a blank when Imported data is not filled in Writing
Points
Check (Filling Data is available)
Filling Data
Space (0 20)
