26.1 System Configuration
26 - 3
25
BAR CODE READER CONNECTION
26
PRINTER CONNECTION
27
CNC CONNECTION
28
MULTI-CHANNEL FUNCTION
29
FA TRANSPARENT FUNCTION
30
MULTIPLE-GT11 CONNECTION FUNCTION
31
GATEWAY FUNCTION INDEX
2 System equipment
(1) GOT
*1 GOT does not support some PictBridge Compatible Printers. For connectable printer types, refer to the following
Technical News.
http://wwwf2.mitsubishielectric.co.jp/melfansweb/english/index_e.htm
List of valid devices applicable for GOT1000 series (T10-0039)
(2) Printer
Remark
Technical News
Visit the Mitsubishi Electric FA Equipment Information Service website (MELFANS
web) to refer to the Technical News.
http://wwwf2.mitsubishielectric.co.jp/melfansweb/english/index_e.htm
(3) Cable
Image No. Name Model name
Printer unit
• For communication between
GOT and PictBrigde
Compatible Printer
*1
GT15-PRN
Image No. Name Model name
PictBridge Compartible Printer
For connectable printers and system equipment, refer to the following Technical
News.
List of valid devices applicable for GOT1000 series (T10-0039)
Image No Name Model name
cable for printer connection
only
GT09-C30USB-5P(3m)(packed together with the printer unit)
Printer
Printer

Mitsubishi GOT1000 Series Specifications

General

Power Supply	24 VDC
Type	HMI (Human Machine Interface)
Series	GOT1000
Resolution	640 x 480 pixels
Touch Panel Type	Resistive
Interface	RS-232, USB
Storage Temperature	-20 to 60°C
Protection Rating	IP65
Display Type	TFT LCD
Brightness	400 cd/m²
Backlight Life	50, 000 hours
CPU	RISC
Shock Resistance	147 m/s²
Display Size	10.4 inches
