4.4 PLC Side Setting
4.4.3 Connecting computer link module
4 - 49
1
OVERVIEW
2
BUS CONNECTION
3
DIRECT CONNECTION
TO CPU
4
COMPUTER LINK
CONNECTION
5
MELSECNET/10
CONNECTION (PLC TO
PLC NETWORK)
6
CC-Link CONNECTION
(INTELLIGENT DEVICE
STATION)
7
CC-Link CONNECTION
(Via G4)
8
ETHERNET
CONNECTION
• Transmission speed setting (SW05 to SW07)
Set the transmission speed (SW05 to SW07) as follows.
The transmission speed setting must be consistent with that of the GOT side.
For how to set the GOT side transmission speed, refer to the following.
Section 4.3.3 Setting communication interface (Communication settings)
*1 Only transmission speeds available on the GOT side are shown.
(d) A1SCPUC24-R2
• Transmission speed setting (2 to 4)
Set the transmission speed (2 to 4) as follows.
The transmission speed setting must be consistent with that of the GOT side.
For how to set the GOT side transmission speed, refer to the following.
Section 4.3.3 Setting communication interface (Communication settings)
*2 Only transmission speeds available on the GOT side are shown.
Setting switch
Transmission speed
*1
4800bps 9600bps 19200bps
SW05 OFF ON OFF
SW06 OFF OFF ON
SW07 ON ON ON
Transmission specifications
switch
Setting
switch
Description Setting
1
Write during RUN
enabled/disabled
setting
Enabled ON
2
Transmission speed
setting
(Consistent with the
GOT side
specifications.)
See descriptions
below.
3
4
5 Data bit setting 8 bits ON
6 Parity bit setting Set ON
7
Even/odd parity
setting
Odd OFF
8 Stop bit setting 1 bit OFF
9 Sum check setting Set ON
Setting switch
Transmission speed
*2
4800bps 9600bps 19200bps
2 OFF ON OFF
3OFFOFFON
4 ONONON
ON
123456789
To Next Page
