5.3 PLC Side Setting
5.3.2 Connecting to MELSECNET/10 network module (QnA Series)
(2) Network range assignment
: Necessary : As necessary : Not necessary
*1 Be sure to set the setting to perform the cyclic transmission.
When changing the network parameter
After writing the network parameter to the PLC CPU, operate the PLC CPU ether
turning OFF and then ON or resetting.
Item Setting
Setting necessity at GOT
connection
Monitoring time 200
BW setting
*1
Send
range for
station
(B)
Station
No.1
Start 0000H
End 00FFH
Station
No.2
Start 0100H
End 01FFH
Send
range for
station
(W)
Station
No.1
Start 0000H
End 00FFH
Station
No.2
Start 0100H
End 01FFH
XY setting
*1
No setting
Specify I/O master station
*1
No setting
Specify reserved station No setting
Supplementary setting
(Use default value)
Station inherent parameters
