CONNECTION TO
ALLEN-BRADLEY
PLC
17.1 System Configuration . . . . . . . . . page 17-2
This section describes the equipment and cables needed
when connecting a GOT to an Allen-Bradley PLC.
Select a system suitable for your application.
17.2 Connection Cable . . . . . . . . . . . . page 17-7
This section describes the specifications of the cables
needed when connecting a GOT to an Allen-Bradley PLC.
Check the specifications of the connection cables.
17.3 Preparatory Procedures for Monitoring
. . . . . . . . . . . . . . . . . . . . . . . . . page 17-10
This section provides the procedures to be followed before
performing monitoring in connection to an Allen-Bradley
PLC.
The procedures are written on the step-by-step basis so
that even a novice GOT user can follow them to start
communications.
17.4 PLC Side Setting . . . . . . . . . . . . page 17-22
The PLC side settings for GOT connection are explained.
When checking the PLC side settings, refer to this section.
