19 - 54
19.5 Message Formats
19.5.6 Formats 11 to 13 (Digital Electronics Corporation's memory link method)
(4) Number of points
Specifies the number of device data to be read/written. (Setting range: 1 to 40
H)
Data notated in Hex is converted to a 4-digit ASCII code (Hex) and transmitted from the upper digit.
(5) Year, month, day, hour, minute, second and day of the week data
Specifies year, month, day, hour, minute, second, and day of the week to be read/set to the GOT
clock data.
Data notated in decimal is converted to a 2-digit ASCII code (Hex) and transmitted from the upper
digit.
(1)Read clock data (N) command
(2)Set clock data (M) command
(6) Error Code
This is the response message at faulty communication appended with error contents.
Data notated in Hex is converted to a 2-digit ASCII code (Hex) and transmitted from the upper digit.
For details of error codes generated in formats 12 and 13 (Digital Electronics Corporation's memory
link method (extended mode)), refer to the following:
Error code list
When connecting a microcomputer, etc. that uses the protocol of the Digital
Electronics Corporation's memory link method with the GOT
When connecting a microcomputer, etc. that uses the protocol of the Digital
Electronics Corporation's memory link method with the GOT, correct the commands
to be used and the device ranges to match the specifications of the GOT.
