19.5 Message Formats
19.5.6 Formats 11 to 13 (Digital Electronics Corporation's memory link method)
19 - 55
17
CONNECTION TO
ALLEN-BRADLEY PLC
18
CONNECTION TO
SIEMENS PLC
19
MICROCOMPUTER
CONNECTION
20
CONNECTION TO OMRON
TEMPERATURE
CONTROLLER
21
CONNECTION TO
YAMATAKE TEMPERATURE
CONTROLLER
22
CONNECTION TO RKC
TEMPERATURE
CONTROLLER
23
CONNECTION TO
FREQROL SERIES
INVERTER
24
SERVO AMPLIFIER
CONNECTION
3 Message Format
The following shows the message format of the dedicated command of the GOT for a microcomputer
connection.
(1) Read clock data (N) command
The following shows an example of reading the clock data of GOT.
(Assuming that the clock data of GOT has been set to "2004, June 1, 18:46:49, Tuesday".)
Item Message format
Request message
(host GOT)
Example: Format 13 (Digital Electronics Corporation's memory link method (extended mode, ASCII code 1:n))
Response
message during
normal
communication
(GOT host)
Example: Format 13 (Digital Electronics Corporation's memory link method (extended mode, ASCII code 1:n))
Response
message during
faulty
communication
(GOT host)
Example: Format 13 (Digital Electronics Corporation's memory link method (extended mode, ASCII code 1:n))
Time display
2004/06/01 18:46:49
TUE
This range Sum check
05
H
ENQ
(H) (L)
CE
43
H 45H
Sum
Check
(H) (L)
Station No.
0
30
H
0
30
H 1BH
ESC
4E
H
N
0D
H
CR
0A
H
LF
Com-
mand
This range Sum check
02
H
STX
(H) (L)
8E
38
H 45H
Sum
Check
(H) (L)
Station No.
0
30
H
0
30
H 1BH
ESC
41
H
A
0D
H
CR
0A
H
LF
(H) (L)
Year data
04
30
H 34H
(H) (L)
Month data
06
30
H 36H
(H) (L)
Day data
01
30
H 31H
(H) (L)
Hour data
18
31
H 38H
(H) (L)
Minute data
46
34
H 36H
(H) (L)
Second
data
49
34
H 39H
(H) (L)
Day-of-
week data
02
30
H 32H
*1
Following
*1
03H
ETX
Com-
mand
The above is a case where the sum
check error (06
H) has occurred.
15
H
NAK
(H) (L)
30
H 36H
Error code
(H) (L)
30
H
Station No.
0
30
H
006
0D
H
CR
0A
H
LF
To Next Page
